Frap Tools CGM Creative Mixer - Master

The CGM Creative Mixer - Master, from Frap Tools, is a versatile 6HP mixer for Eurorack.
It provides all the essential components required for studio and live performance.
Users can link a total of eight channels in a single group, and connect four groups to a master.

The Channel module governs mono signals via its 3.5mm mono input and is comprised of a stereo VCA with corresponding CV jack, attenuator, a post-main VCA with direct output capability, dual parallel sends with mono VCA with corresponding CV jack and attenuator governing the send and pre/post fader switch.
Additionally, the module features a Pan control with offset pot and CV. There’s also latching buttons that afford mute, solo, and PFL, all of which govern the input signal before routing it to the Group.

FEATURES:

• Channels section of CGM Creative Mixer
• 8 Channels modules can be connected to a single Group module
• Manages mono signals via 3.5mm mono input jack
• Main stereo VCA with CV in and attenuator
• Direct output post main VCA
• Two parallel sends with mono VCA for each send
• Pan control with offset CV and knob

Video: https://youtu.be/m_zQMu99ggk

Product Specs

• Item Number: 16831
• Make: Frap Tools
• Model: CGM Creative Mixer - Master
• Condition: Brand New
• Finish: Thin Film Interference
• Categories: keyboards-and-synths ⇒ eurorack
• Function: Expander Mixer Utility
• Made In: Italy
• MPN: F-MAS0-MX
• Modular Grid: Eurorack ⓘ ＋
• Dimensions: 6 HP 43 mm deep
• Power: 62 mA +12V 44 mA -12V 0 mA 5V
